| FRAME | 57cm Hardtail alloy with intenal cable routing |
|---|
| DRIVE UNIT | Shimano STEPS E6100, 36V, 250W, 60Nm |
|---|
| BATTERY | Darfon, 36V, 504 Wh, integrated |
|---|
| BATTERY RANGE | Up to 185km * This will vary depending on the weight of the user, terrain and mode of pedal assistance used |
|---|
| CHARGER | |
|---|
| DISPLAY | Shimano SC-E6100, clamp band |
|---|
| FORK | SR Suntour NEX-DS, 1-1/8", coil, QR type, 50mm travel |
|---|
| CRANKSET | |
|---|
| PEDALS | Marwi SP-823 |
|---|
| REAR DERAILLEUR | Shimano Deore RD-T6000 Shadow |
|---|
| SHIFTER | Shimano Deore SL-M6000-R rapid fire Plus, 10-speed |
|---|
| CASSETTE | Shimano CS-HG500-10, 11-34T |
|---|
| CHAIN | |
|---|
| WHEELSET | Shimano HB-M3050, 36H, center lock , QR type,Shimano FH-M3050, 36H, center lock, M10x135mm, QR type |
|---|
| TYRES | CST Xpedium Ampero, 700x38C, reflective tape |
|---|
| BRAKESET | Shimano BL-MT200/BR-MT200, hydraulic disc brake |
|---|
| HEADSET | Acros AZX-254, ZS44/28.6 | EC49/30, block lock 150° |
|---|
| HANDLEBAR | ONE1 Alloy, CHBA6354, 30° backsweep, 16mm rise, 620mm, 31.8mm |
|---|
| STEM | ONE1 TDS-C2698 Alloy, 31.8mm, 0°/+90° |
|---|
| GRIPS | Herrmans Line DD36BR, Herrmans Line DD36BL |
|---|
| SADDLE | |
|---|
| SEATPOST | ONE1 Alloy, SP S405, 30.9mm |
|---|
| HEADLIGHT | |
|---|
| TAILLIGHT | |
|---|
| REAR CARRIER | With AVS system for easy attaching of bags |
|---|
| ACCESSORIES | Carrier, mudguards, lights, kickstand |
|---|
